Sumo LD Next Gen

Motor/Inverter System

Discover The Right Motor

Learn more

About

The TM4 SUMO MD systems are designed to interface directly with standard axles (no gearbox required). It makes this series perfect for class 4 to 7 commercial vehicles, bus platforms, and off-highway applications.

Light Commercial

Light FLatbed

Tractor

Dump truck

Box truck

Coach bus

Heavy-Duty Flatbed

City bus

Features & benefits

Peak power

Up to 265 kW

Peak torque

Up to 3320 Nm

Max operating speed

3700 RPM

High torque/low speed permanent magnet motor and inverter combinations

Designed to interface directly with standard axles (no gearbox required)

Details

Standards

System protection: IP67 / IP6K9K

Automotive components: AEC-Q100 / AEC-Q101 / AEC-Q200

Electromagnetic compatibility EMC: Main automotive international standards

Shock and vibration standards: GMW3172 Sprung masses

Max coolant inlet temperature: 65°C

Coolant type: 40/60 water-glycol

Motor features

Proven permanent magnet technology for optimal efficiency

Outer rotor topology for maximum torque density

Low electro-magnetic audible noise

Low-cogging and ripple torque for better NVH

Four-quadrant operation

Latest system Features [NEW]

Voltage increase: 750 V to 800 V

Quick Connect with HVIL for safe and easy installation or maintenance

Increased performances range

KITAS option available on demand

INverter Features

3-phase or 6-phase high-voltage inverter

Variable switching frequency

Reflex™ gate driver technology for high power and current densities

EMI Filter

Best-in-class power density

High efficiency

Some image caption

Technical Drawing

Product Table
System	Inverter	Continuous power	Peak torque	Continous torque	Range
SUMO MD MV2500-6P*	CO200	230 kW	2500 Nm	3000 RPM	130-450 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name*	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name**	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc
System Name	CO200	0 kW	0 Nm	0 Nm	0-100 Vdc

600 Vdc, 45°C / *350 Vdc, 45°C / **600 Vdc, 45°C

Specifications are subject to change
